ST6 LED Directional Lamp - Super Thin Series Amber Red


Price:
Sale price
Stock:
Sold out

Description

PRODUCT DESCRIPTION

Super Thin 6 LED Directional Dual Colour - ST6

Dimensions: 112.6mm (L) x 28.1mm (H) x 9mm (D)

Features:

  • World renowned ST6 is now available in 6+6 LED Dual Colour.
  • Multi-memories design for instant switch between selected flash patterns and/or colours.
  • ECE R10 EMC Compliance.
  • 0.35” (9mm) Super low-profile optic with ECE R65 (XA1, XB1, XR1) and SAE Class 1 certified output.
  • Self-contained; no external flasher required.
  • Non-volatile memory recalls last flash pattern used at power up.
  • Multi-units synchronization in simultaneous or alternating flash.
  • Reverse polarity and load dump protection.
  • Fully weatherproof and vibration resistant design for internal or external use.
  • Solid aluminum base for efficient heat dissipation and maximum durability.
  • Part No - LEDDST6

Specifications:

  • Compliance: ECE R65 (XA1, XB1, XR1), ECE R10, IPX7, SAE J595 Class 1, SAE J845 Class 1, CISPRR 25
  • LED Element: High-power LED x 12pcs
  • No. of Warning Patterns: 28
  • Operating Voltage: 12~24VDC
  • Avg. Current: 0.44A @12VDC / 0.22A @24VDC (varies with flash pattern)
  • Avg. Power: 5.2 Watts (varies with flash pattern)
  • Max. Current: 0.87A @12VDC / 0.44A @24VDC
  • Max. Power: 10.4 Watts
  • Wires: Black - GND: 21cm (AWG) / Red - Warning Memory 1: 21cm (20AWG) / White - Warning Memory 2: 21cm (20AWG) / Yellow - Flash Patterns & Sync: 21cm (20AWG)
  • Fuse Rating: 1A
  • Synchronization: 15 Units
  • LED Colour: Red, Blue, Amber, White (any 2 colours)
  • Lens Colour: Clear
  • Storage Temp. (°C): -40°C to +75°C
  • Working Temp. (°C): -30°C to +65°C
  • Warranty: 5 Years
