LEDDMS6 6 LED Directional

PRODUCT DESCRIPTION

Dimensions: 107mm (L) x 24mm (H)  x 42mm (D)

Features:

• R65 Class 2 super high power output.
• Super low profile discreet mounting.
• 12-24VDC Multi-Voltage Input.
• Built-in 5 selectable flash patterns.
• Long life LEDs rated to 100,000 hours of reliable operation.
• Non-volatile memory recalls last flash pattern used at power up.
• Multi-units synchronization.
• Reverse polarity protection.
• Weatherproof and vibration resistant design for versatile application.
• Aluminum base for efficient heat dissipation.

Specifications:

• Meets: ECE R65 (XA2, XB2), ECE R10
• Bulb: High-power LED x 6pcs
• Warning Patterns: 5 Flash Patterns
• Operating Voltage: 12~24VDC
• Avg. Current: 0.58A@12VDC / 0.29A@24VDC
• Avg. Power: 6.9W
• Max. Current: 1.15A@12VDC / 0.58A@24VDC
• Max. Power: 13.8W
• Wires(M30): Red-Vcc : 20cm (20AWG) / Black-GND : 20cm (20AWG) / Yellow-Flash Patterns & Sync : 20cm (20AWG) / White-Low Power : 20cm (20AWG)
• Wires(M29): Red-Vcc : 97cm (20AWG) / Black-GND : 97cm (20AWG) / Yellow-Flash Patterns & Sync : 97cm (20AWG) / White-Low Power : 97cm (20AWG)
• Fuse Recommended: 2A
• Multi-Unit Synchronization: Over 15 units
• Available in: BLUE, AMBER
