LEDDAL6-MM (M58) Mirror Mount

ELSSKU: LEDDAL6-MM

Price:
Sale price
Stock:
Sold out

Description

PRODUCT DESCRIPTION

Dimensions: 96.8mm (L) x 34.5mm (H)  x 37.4mm (D)

Features:

  • Super wide-angle output rated with SAE and ECE R65 Class 1.
  • Versatile Surface Mount with or without bezel, suitable for all vehicle bodies and motorcycle storage boxes.
  • Non-volatile memory recalls last flash pattern used at power up.
  • Multi-units synchronization in simultaneous or alternating flash.
  • Reverse polarity protection.
  • Fully weatherproof and vibration resistant design for external or internal use.
  • Aluminum base for efficient heat dissipation and maximum durability.

Specifications:

  • Meets: SAE J595 & J845 (R,A,B,W), IPX7, ECE R65 (XA1, XB1), ECE R10
  • Bulb: High-power LED x 6pcs
  • Warning Patterns: 16 Flash Patterns
  • Operating Voltage: 12~24VDC
  • Avg. Current: 0.57A @12VDC / 0.285A @24VDC (varies with flash pattern)
  • Avg. Power: 6.84 Watts (varies with flash pattern)
  • Max. Current: 1.14A @12VDC / 0.57A @24VDC
  • Max. Power: 13.7 Watts
  • Wires: Red-Vcc : 20cm (20AWG) / Black-GND : 20cm (20AWG) / Yellow-Flash Patterns & Sync : 20cm (20AWG)
  • Fuse Recommended: 2A
  • Multi-Unit Synchronization: Over 15 units
  • Available in: RED, BLUE, AMBER, WHITE
